FX PCB manufacture for Display PCB
Contents
show
FX PCB can produce 1-24 Layer display PCB for our customers, and we help customers from prototype to mass production with competitive price. Our experienced engineer team will give you the suggestion on your design to improve your product efficiency, yield and control the PCB cost. We are flexible on the delivery time, as we support customer with expedited time and standard delivery time to choose. Please send us your Gerber file or questions, and our sales will contact you in 24 hours.
FX PCB Capability
| Item | Process Capability |
| Layer Counts | 1-24L |
| Material | FR-4,Ceramic,Alu Base, Cu Base, Rogers,etc. |
| Maximum Size | 600mm x 1500mm |
| Board Outline Tolerance | ± 0.10mm |
| Board Thickness | 0.20mm—8.00mm |
| Thickness Tolerance(t ≥ 0.8mm) | ± 8% |
| Thickness Tolerance(t < 0.8mm) | ± 10% |
| Insulation Layer Thickness | 0.075mm—5.00mm |
| Minimum Line | 0.075mm |
| Minimum Space | 0.075mm |
| Out Layer Copper Thickness | 18um—350mm |
| Inner Layer Copper Thickness | 17um—210mm |
| Drilling Hole(Mechanical) | 0.15mm—6.35mm |
| Finish Hole(Mechanical) | 0.10mm—6.30mm |
| Diameter Tolerance(Mechanical) | 0.05mm |
| Registration(Mechanical) | 0.075mm |
| Aspect Ratio | 16 : 1 |
| Solder Mask Type | LPI |
| SMT Mini. Solder Mask Width | 0.075mm |
| Mini. Solder Mask Clearance | 0.05mm |
| Plug Hole Diameter | 0.25mm—0.60mm |
| Impedance Control Tolerance | ± 10% |
| Surface Finish | HASL, ENIG, Chem.Tin, Chem Silver.Flash Gold, OSP, Gold finger |
