Description
| Items | Mass Production | Low Volume | |
| Total Layers | 2～16L | 20L | |
| Layers of sofe | 10L | 16L | |
| PCB Thickness | ≤2.4mm | / | |
| Line width/Line space | Inner layer | 3mil/3mil (HOz) | 2.5mil/2.5mil (HOz) |
| Outer layer | 4mil/4mil (1Oz) | 3mil/3mil (1Oz) | |
| Hole Ring | ≥6mil | 4mil | |
| Impedance Control | +/-10% | / | |
| Drilling | Machine drilling | ≥8mil | 6mil |
| Laser drilling | 5mil/6mil | 4mil | |
| Aspect Ratio | 10:01 | 16:01 | |
| Surface Coating | ENIG, Immersion Silver, Immersion Tin, OSP | ||
Why you need to choose the Flex PCB?
- Flex PCBs are incredibly space-saving. In fact, it only requires 10% of space compared to the conventional standard PCBs. It offers great freedom when it comes to packaging and installation.
- You can achieve the tightest blend capacity with the flex PCBs. Its permeability and flexibility offer such bending.
- The flex boards work with only a minimal number of interconnections. Fewer connections mean the PCB will need fewer solder joints and contact crimps. It implies that fewer loopholes are resulting in the least failures. Thus, it dramatically enhances the reliability of the components.
- It works with every possible connector and component available in the market. Also, it works better with ZIP connectors. So, you get enhanced capabilities with the use of these circuits.
- The flexible circuits are made to function under extreme and challenging conditions. So, these circuits won’t face reduced performance even when the temperature is high or in the presence of chemicals and radiation. To put it simply, these are temperature, chemical, and radiation-resistant.
- Flexible circuits have fewer connections and components. Also, it comes in a smaller size. All these results in an extreme saving of flexible PCB cost. So, you can save a considerable amount with the flexible circuits.
