6-Layer PCB Vs 4-Layer PCB?
A 6-layer PCB is a printed circuit board made up of six layers of material, created using chemical etching. Compared to double-sided and 4-layer PCBs, 6-layer PCBs offer more circuit layers, higher wiring density, and better resistance to interference. Additionally, advanced techniques like blind vias and buried vias can be used to further enhance
Manufacturing Process of 6-Layer PCBs
The manufacturing process of a 6-layer PCB includes the following steps:
material selection, circuit design, inner and outer layer production, pattern transfer, chemical etching, electroplating, drilling, circuit pattern deposition, copper lamination, CNC, and testing. Inner and outer layer production, chemical etching, and electroplating are critical steps that directly affect the quality and performance of the PCB.
6-layer PCBs are widely used high-performance printed circuit boards in modern electronics, offering advantages like multilayer routing, high density, and high-speed signal transmission. During the design process, following specific layer design rules is crucial, such as ensuring symmetrical inner layer layouts, isolating signal layers from ground layers, avoiding ground layers between adjacent signal layers, and minimizing the number of vias. By carefully controlling each step of the manufacturing process, high-quality and high-performance 6-layer PCBs can be produced, providing a reliable foundation for the development of modern electronic products.
Capability of 6-Layer PCB
Layers: 6
Material: FR4
Thickness: 0.6mm – 10mm
Copper Weight: 1/2oz – 10oz per layer
Surface Finish: HASL, ENIG, OSP, or others
Min. Line Width/Spacing: 0.07mm/0.07mm
Min. Hole Size: 0.15mm
Impedance Control: YES
Blinded and Buried Holes: YES
Why Choose FX PCB 6-Layer PCBs?
- Advanced Manufacturing Process: Leveraging cutting-edge technology to deliver flawless multilayer boards.
- Fast Turnaround Times: Quick prototyping and production to keep your project on schedule.
- Strict Quality Control: Every PCB will be tested before shipping to ensure it meets or exceeds industry standards.
- Eco-Friendly Practices: All PCBs are Rohs and Reach meet
How to Order
Getting started is easy:
- Submit your design files (Gerber).
- Specify your material, thickness, finish, and any special requirements.
- Receive a free quote within 24 hours.
- Approve and place your order.
- Get your PCBs delivered fast!
Frequently Asked Questions
Q: What kind of file you can use to produce the PCB?
Gerber file, eagle file, PCB file
Q: What kind of payment can you make?
TT, Paypal, Payoneer, WeChat Pay, Alipay
Q: What is your lead time?
A: Standard production takes 5-10 business days. Expedited services are available upon request.
Get Started Today
Don’t settle for less when your projects demand the best. Contact FX PCB now for a free consultation or to request a quote. Let’s bring your designs to life with our high-quality 6-layer PCBs.
