FR4 PCB Boards

FR4 is a glass-reinforced epoxy laminate rated for flame resistance (Flame Retardant Grade 4). It is the industry-standard PCB substrate due to its excellent mechanical strength, high insulation resistance, low moisture absorption, and cost-effectiveness. It supports a wide range of surface finishes, layer counts, and copper weights, making it suitable for consumer electronics through to aerospace applications.

FX PCB manufactures FR4 PCBs with layer counts ranging from 1 to 68 layers. Standard configurations include single-sided, double-sided, and multilayer (4, 6, 8, and above). Custom layer configurations are available to meet specific design complexity, signal routing, and density requirements for both prototype and mass production orders.

Standard FR4 has a glass transition temperature (Tg) of approximately 130–140°C, suitable for most general electronics. High-Tg FR4 (Tg150, Tg170, Tg180) withstands temperatures of 180°C or above without deformation or loss of mechanical integrity. High-Tg boards are recommended for applications with lead-free soldering, dense component placement, or operation in high-heat environments such as automotive, aerospace, and industrial control systems.

FX PCB's FR4 PCBs are manufactured in ISO9001, ISO13485, and ISO14001 certified facilities. All boards are UL Listed, RoHS and REACH compliant, and meet IPC standards including IPC-A-610 Class 2/3 for assembly. Every bare board undergoes 100% electrical testing before dispatch, and compliance documentation can be provided upon request.

FX PCB offers FR4 PCBs with copper thickness ranging from standard (1 oz or less) up to ultra-heavy weights of 20 oz. Heavy copper PCBs with up to 20 oz copper thickness are designed for high current carrying capacity and are ideal for demanding applications in automotive, industrial, and power electronics.

FX PCB's FR4 PCBs support a range of advanced capabilities including impedance control, blind and buried vias, high current capacity (via heavy copper up to 20 oz), thermal management (including Copper Coin PCBs with embedded copper for direct heat dissipation), and high-frequency performance. These capabilities make them suitable for complex designs in aerospace, telecommunications, medical, and automotive industries.

FX PCB delivers official custom quotes within 24 hours. To receive a quote, simply submit your Gerber files or design specifications. FX PCB's engineers will respond with a detailed quote and a DFM (Design for Manufacturability) review, covering prototype through to high-volume mass production requirements.
