Rigid Flexible PCB for High-Reliability Electronics

A rigid-flex PCB is a hybrid circuit board that integrates rigid FR4 sections and flexible polyimide layers into a single board. This design eliminates the need for separate connectors between boards, reducing weight and improving reliability. It is widely used in aerospace, medical devices, wearables, and other applications where compact, durable, three-dimensional circuit routing is required.

SFX PCB's rigid-flex boards support up to 20 total layers, including up to 12 flexible layers. This multilayer capability enables complex signal routing, dedicated power and ground planes, and impedance-controlled traces — making them suitable for high-speed digital, RF, and high-density interconnect applications in aerospace, medical, and telecom sectors.

Rigid-flex PCBs use polyimide (PI) for the flexible sections due to its excellent thermal stability and bendability, and FR4 for the rigid sections for structural support. Premium builds may incorporate Rogers materials for high-frequency RF performance. Supplier-qualified materials including Shengyi, DuPont, and Taiflex are used to ensure consistent quality.

Available surface finishes include ENIG (Electroless Nickel Immersion Gold), OSP (Organic Solderability Preservative), HAL Lead-free, Immersion Silver, Immersion Tin, ENEPIG, Soft Gold, and Gold Plating. ENIG is popular for fine-pitch components and long shelf life, while HAL Lead-free is chosen for RoHS-compliant applications.

SFX PCB's rigid-flex boards are manufactured under ISO 9001:2015, ISO 14001:2015, and ISO 13485 certified quality management systems, with IPC Class II and IPC-A-610 Class 2/3 inspection standards applied. Each board undergoes 100% electrical testing, impedance testing, AOI, and dimensional inspection before shipment, ensuring consistent quality for mission-critical applications.

Rigid-flex PCBs are used across aerospace and defense (radars, guidance systems, night vision), medical devices (defibrillators, hearing aids, ultrasound), automotive (ABS systems, dashboards, transport control), telecommunications (smartphones, base stations), industrial automation, and consumer electronics. Their ability to reduce weight, eliminate connectors, and fit into complex 3D enclosures makes them ideal for demanding, space-constrained designs.

SFX PCB's engineering team responds with a detailed stack-up review and pricing within 24 hours of receiving your PCB files and requirements. Every bare board also ships with 100% electrical testing completed, ensuring confidence in quality from quote through delivery.
