Metal Core PCBs for Medical Devices

SFX PCB holds ISO 13485 certification for medical device quality management, along with ISO 9001 for general quality systems, ISO 14001 for environmental management, IPC-A-610 Class 2 and Class 3 assembly standards, RoHS compliance, REACH compliance, and UL certification. These credentials ensure every medical-grade MCPCB meets the highest regulatory and safety requirements.

Aluminum core PCBs offer an excellent cost-to-performance balance with thermal conductivity of 1–3 W/MK, making them suitable for most medical lighting and monitoring devices. Copper core PCBs deliver thermal conductivity up to 400 W/MK with superior dimensional stability, making them ideal for high-power medical equipment such as imaging systems and surgical lasers where extreme heat dissipation is required.

SFX PCB offers a wide range of copper weights from Standard (0.5–1 oz) for general medical circuitry, Medium (2–4 oz) for moderate power applications, Heavy (5–10 oz), and Ultra-Heavy (10–20 oz) for the most demanding high-power medical devices. Copper foil thickness options range from 35μm to 210μm to accommodate diverse design requirements.

Aluminum Base PCBs are available in thicknesses from 0.5mm to 5.0mm, while standard metal backing plate options include 1.0mm, 1.5mm, and 3.2mm. Copper Core PCBs are available in 1mm, 1.2mm, 1.5mm, and 2mm standard thicknesses. Custom thicknesses can be accommodated — submit your Gerber files and specifications for a tailored quote.

Yes. SFX PCB's Metal Core PCBs are manufactured in compliance with RoHS and REACH directives, ensuring restriction of hazardous substances and responsible use of materials. Both aluminum and copper substrates are recyclable, supporting environmentally responsible production. These compliance credentials are essential for medical devices entering European, North American, and global markets.

SFX PCB provides official quotations within 24 hours of receiving your PCB files and requirements. Prototypes can be assembled from 24 hours once all components are available. For mass production timelines specific to your medical device project, contact the team directly via email at info@sfxpcb.com or through WhatsApp support for a precise delivery schedule.
