Thermal Clad PCBs and Heat Sink Printed Circuit Boards

In PCB terminology, 'clad' refers to a metal layer bonded to the substrate surface. In thermal clad PCBs, a thermally conductive metal — typically aluminum or copper — is laminated onto the board. This metal cladding acts as a built-in heat spreader, efficiently transferring heat away from components and eliminating the need for external heatsink hardware in many applications.

Thermal in PCB refers to the board's ability to manage, conduct, and dissipate heat generated by electronic components. Thermal PCBs — such as metal core (MCPCB), aluminum base, copper core, and ceramic PCBs — incorporate highly conductive substrates and dielectric layers engineered to move heat away from critical components, preventing thermal runaway and extending product lifespan in high-power applications.

Aluminum PCBs offer thermal conductivity of 1–3 W/MK, making them cost-effective for most LED lighting and power supply applications. Copper Core PCBs achieve up to 400 W/MK, providing dramatically superior heat dissipation for high-density power modules, radar systems, and microwave technology where extreme thermal performance is required. Copper boards also exhibit greater dimensional stability with an elastic modulus of ~121,000 MPa.

Ceramic PCBs — using ALN (≥170 W/m·K) or Al2O3 (≥24 W/m·K) substrates — are preferred for aerospace, high-frequency RF, semiconductor packaging, and medical applications requiring zero water absorption, resistance to cosmic rays, high dielectric strength (≥17 KV/mm), and thermal expansion coefficients that closely match semiconductor components. MCPCBs are better suited for cost-sensitive, high-volume LED and automotive applications.

A Copper Coin PCB embeds a solid copper insert directly beneath a high-heat component, creating a near-direct thermal path through the board. It is used in 5G communications, power amplifiers, RF electronics, and high-density multilayer designs where isolated thermal hotspots require localized extreme cooling without increasing overall board dimensions. The copper coin is available in embedded, press-fit, and T/U-shape configurations.

FX PCB offers multiple surface finish options depending on the board type: Aluminum Base PCBs support HASL, ENIG, OSP, and Silver finishes. Copper Core PCBs are available with OSP, ENIG, and Immersion Tin. Ceramic PCBs use ENIG, ENEPIG, and Immersion Silver. Copper Coin PCBs support ENIG and OSP. The best finish depends on solderability requirements, operating environment, and component assembly method.
