High-Density Interconnect PCB Manufacturers in USA - HDI Boards

HDI stands for High-Density Interconnect. In PCB manufacturing, it refers to boards designed with very dense routing, finer traces and spaces, smaller vias, and often laser-drilled microvias. HDI technology allows more circuitry to fit into a smaller board area, making it useful for compact electronics such as medical devices, telecom equipment, consumer products, robotics, and advanced industrial systems.

A regular PCB typically uses larger vias, wider traces, and more conventional layer routing. An HDI PCB uses finer features, microvias, tighter spacing, and more advanced stackups to support compact and high-performance designs. HDI boards can reduce board size, improve signal paths, and enable higher component density, but they require tighter manufacturing controls and stronger design-for-manufacturability review.

Yes. FX PCB supports USA and North American customers through its Plano, Texas office while manufacturing through certified PCB and PCBA facilities in Shenzhen. This structure gives engineering teams local-facing communication, direct manufacturer pricing, and access to advanced production capabilities, including fine line/space fabrication, laser drilling, assembly, sourcing, and testing for compact electronics programs.

For an accurate HDI PCB quote, provide Gerber files, drill files, stackup requirements, board dimensions, material preferences, surface finish, copper weight, impedance requirements if applicable, quantity, and delivery expectations. If assembly is needed, include a BOM, pick-and-place files, assembly drawings, and testing requirements so sourcing, placement, and inspection can be evaluated together.

Yes. FX PCB offers turnkey PCB assembly services that can combine HDI board fabrication with SMT and THT assembly, component sourcing, programming, inspection, and functional testing. This is helpful for dense designs because the bare board, components, placement constraints, and test strategy can be coordinated under one production workflow instead of split between multiple vendors.

DFM analysis reviews the design before production to identify issues such as impractical trace spacing, via structures, drill constraints, annular ring concerns, stackup risks, and assembly challenges. FX PCB provides free DFM analysis for every order, helping teams reduce rework, improve yield, control cost, and avoid delays before a dense HDI design reaches fabrication.

FX PCB operates certified facilities, including ISO9001, ISO14001, and ISO13485, and follows IPC-A-610 Class 2/3 assembly standards. Quality controls may include AOI, X-ray inspection, functional testing, and 100% electrical testing on bare boards. RoHS and REACH compliance are also available to support products intended for regulated global markets.

Turnaround depends on board complexity, layer count, material availability, component sourcing, and testing requirements. FX PCB supports fast-turnaround prototyping and can assemble boards from 24 hours once all parts are available. Standard PCB assembly delivery is often 1–2 weeks, with expedited options available when project timing requires faster completion.
