Thick Film PCBs

Thick film technology is used in applications requiring excellent thermal management, electrical insulation, and stability under harsh conditions. Common uses include LED lighting modules, power semiconductor packaging, aerospace electronics, automotive control circuits, high-frequency switching power supplies, telecommunications equipment, and semiconductor coolers. The ceramic substrate's high thermal conductivity makes it ideal wherever heat dissipation is critical.

SFX PCB offers Thick Film PCBs on two ceramic substrates: Aluminum Nitride (ALN) and Aluminum Oxide/Alumina (Al2O3). ALN provides superior thermal conductivity of ≥170 W/(m·K) for the most demanding heat dissipation requirements, while Al2O3 offers ≥24 W/(m·K) with excellent electrical insulation and is a cost-effective choice for many high-frequency and power applications.

Available surface finishes include ENIG (Electroless Nickel Immersion Gold), ENEPIG (Electroless Nickel Electroless Palladium Immersion Gold), and Immersion Silver. Each finish offers distinct advantages: ENIG provides reliable solderability and corrosion resistance, ENEPIG is ideal for wire bonding and fine-pitch components, and Immersion Silver offers excellent conductivity at a competitive cost.

SFX PCB's Ceramic PCBs support a minimum track width and spacing of 0.075 mm using DPC (Direct Plate Copper) technology. This fine-line capability enables complex, high-density circuit designs suitable for demanding aerospace, military, and miniaturized power electronic applications without compromising electrical performance or reliability.

Yes. Ceramic Thick Film PCBs are well-suited for aerospace and military applications. The ceramic substrate contains no organic materials, providing inherent resistance to cosmic radiation. These boards meet high dielectric strength (≥17 KV/mm), offer thermal expansion coefficients closely matched to semiconductor components, and are tested per Chinese national standards for use in radiation-exposed and high-reliability environments.

Yes. SFX PCB supports the full production lifecycle from single prototypes to high-volume mass production runs. Every order benefits from a free DFM (Design for Manufacturability) analysis, and the company offers turnkey PCBA services including SMT assembly, through-hole (THT) assembly, component sourcing, and functional testing — all managed in-house to ensure quality and lead time consistency.
