Single Sided Copper PCB Boards

Single sided copper PCBs can be manufactured on a range of substrates including FR4 fiberglass, polyimide (PI) for flexible variants, aluminum for thermal management, copper core for maximum heat dissipation, and ceramic (ALN or Al2O3) for high-frequency or high-temperature applications. Material choice depends on thermal, mechanical, and electrical requirements.

Available surface finishes include HASL (Hot Air Solder Leveling), Lead-free HASL, ENIG (Electroless Nickel Immersion Gold), OSP (Organic Solderability Preservative), Immersion Silver, Immersion Tin, and ENEPIG. Each finish offers different benefits in terms of solderability, shelf life, and compatibility with RoHS compliance requirements.

Copper weight options range from standard 0.5–1 oz for general-purpose designs, medium 2–4 oz for moderate power requirements, heavy 5–10 oz for high-current applications, and ultra-heavy 10–20 oz for extreme power or thermal demands. Aluminum and copper core boards support copper foil from 1 oz to 10 oz, with ceramic boards offering 18–300 µm (0.5–8.5 oz).

Yes. Single sided aluminum base and metal core PCB variants dissipate heat significantly faster than standard FR4 boards — up to 9x more efficiently. Copper core options achieve thermal conductivity up to 400 W/MK. These boards eliminate the need for separate heat sinks and are widely used in LED lighting, power supplies, and automotive electronics.

Yes. SFX PCB offers full turnkey PCB assembly services, including SMT and through-hole (THT) component placement, component sourcing from over 600,000 local stock items, and functional testing. Both prototype quantities and high-volume production runs are supported, allowing you to receive a fully tested, ready-to-use assembly rather than a bare board.

Quotes are typically delivered within 24 hours of receiving your Gerber files or design requirements. For stack-up-specific inquiries, a response is provided within 8 hours. Every order also includes a free DFM (Design for Manufacturability) analysis to identify potential manufacturing risks before production begins, helping reduce costly rework.
